Tekiò Horizontal
2017
Tekiò Horizontal
Biographies
Anthony Dickens
After founding his first studio in 1998, Anthony Dickens founded Studio Make Believe in 2015, designing objects that express simple narratives and reimagine the everyday things that surround us. He creates objects that solve problems for some of the world’s leading brands including Ben & Jerry’s, Jose Cuervo, Finlandia, AB Inbev, Red Bull and Pernod Ricard.
Modular solution, extendable up to four sections—ideal for dressing tables or drawing paths through open spaces.
The ancestral meets the avant-garde
Highly technical structures dressed in handmade paper. Alone or in repetition, its luminous power can vary from a whisper to an exclamation.
Discover the possibilitiesThe ancestral meets the avant-garde
Highly technical structures dressed in handmade paper. Alone or in repetition, its luminous power can vary from a whisper to an exclamation.
Discover the possibilitiesOverview
Washi Japanese paper shade.
Metal structure.
2 options of white S&C metallic canopy with power supply incorporated: circular or rectangular.
Dim to Warm control 2200K – 2700K.
Suitable for dimming 0-10V. Not included external dimmer switch 0-10V.
Electric cable length: 5 m / 196.8"
Weight: 3,0 kg / 6.61 lb
Light sources
Built-in LED: Output 34 W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz). According to destination.
CCT: 2.200 - 2.700 K
CRI: 90
Lifetime: 40.000 h
Luminous flux: 964 lm
Overview
Washi Japanese paper shade.
Metal structure.
2 options of white S&C metallic canopy with power supply incorporated: circular or rectangular.
Dim to Warm control 2200K – 2700K.
Suitable for dimming 0-10V. Not included external dimmer switch 0-10V.
Electric cable length: 5 m / 196.8"
Weight: 3,0 kg / 6.61 lb
Light sources
Built-in LED: Output 34 W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz). According to destination.
CCT: 2.200 - 2.700 K
CRI: 90
Lifetime: 40.000 h
Luminous flux: 964 lm
Overview
Washi Japanese paper shade.
Metal structure.
2 options of white S&C metallic canopy with power supply incorporated: circular or rectangular.
Dim to Warm control 2200K – 2700K.
Suitable for dimming 0-10V. Not included external dimmer switch 0-10V.
Electric cable length: 5 m / 196.8"
Weight: 4,5 kg / 9.92 lb
Light sources
Built-in LED: Output 56 W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz). According to destination.
CCT: 2.200 - 2.700 K
CRI: 90
Lifetime: 40.000 h
Luminous flux: 1.687 lm
Overview
Washi Japanese paper shade.
Metal structure.
2 options of white S&C metallic canopy with power supply incorporated: circular or rectangular.
Dim to Warm control 2200K – 2700K.
Suitable for dimming 0-10V. Not included external dimmer switch 0-10V.
Electric cable length: 5 m / 196.8"
Weight: 4,5 kg / 9.92 lb
Light sources
Built-in LED: Output 56 W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz). According to destination.
CCT: 2.200 - 2.700 K
CRI: 90
Lifetime: 40.000 h
Luminous flux: 1.687 lm
Overview
Washi Japanese paper shade.
Metal structure.
2 options of white S&C metallic canopy with power supply incorporated: circular or rectangular.
Dim to Warm control 2200K – 2700K.
Suitable for dimming 0-10V. Not included external dimmer switch 0-10V.
Electric cable length: 5 m / 196.8"
Weight: 6,0 kg / 13.22 lb
Light sources
Built-in LED: Output 73 W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz). According to destination.
CCT: 2.200 - 2.700 K
CRI: 90
Lifetime: 40.000 h
Luminous flux: 2.315 lm
Overview
Washi Japanese paper shade.
Metal structure.
2 options of white S&C metallic canopy with power supply incorporated: circular or rectangular.
Dim to Warm control 2200K – 2700K.
Suitable for dimming 0-10V. Not included external dimmer switch 0-10V.
Electric cable length: 5 m / 196.8"
Weight: 6,0 kg / 13.22 lb
Light sources
Built-in LED: Output 73 W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz). According to destination.
CCT: 2.200 - 2.700 K
CRI: 90
Lifetime: 40.000 h
Luminous flux: 2.315 lm
Overview
Washi Japanese paper shade.
Metal structure.
2 options of white S&C metallic canopy with power supply incorporated: circular or rectangular.
Dim to Warm control 2200K – 2700K.
Suitable for dimming 0-10V. Not included external dimmer switch 0-10V.
Electric cable length: 5 m / 196.8"
Weight: 7,5 kg / 16.53 lb
Light sources
Built-in LED: Output 87 W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz). According to destination.
CCT: 2.200 - 2.700 K
CRI: 90
Lifetime: 40.000 h
Luminous flux: 3.051 lm
Overview
Washi Japanese paper shade.
Metal structure.
2 options of white S&C metallic canopy with power supply incorporated: circular or rectangular.
Dim to Warm control 2200K – 2700K.
Suitable for dimming 0-10V. Not included external dimmer switch 0-10V.
Electric cable length: 5 m / 196.8"
Weight: 7,5 kg / 16.53 lb
Light sources
Built-in LED: Output 87 W / Input: 120 ~ 277 Vac.
(50 Hz / 60 Hz). According to destination.
CCT: 2.200 - 2.700 K
CRI: 90
Lifetime: 40.000 h
Luminous flux: 3.051 lm
Available modifications
P1 lampshade: Washi Japanese paper
Dimming: 1-10 V
Dimming: DALI
Canopy: Rectangular. Dimming: 1-10 V
Canopy: Rectangular. Dimming: DALI
P1 lampshade: Washi Japanese paper
Dimming: 1-10 V
Dimming: DALI
Canopy: Rectangular. Dimming: 1-10 V
Canopy: Rectangular. Dimming: DALI
P2 lampshade: Washi Japanese paper
Dimming: 1-10 V
Dimming: DALI
Canopy: Rectangular. Dimming: 1-10 V
Canopy: Rectangular. Dimming: DALI
P2 lampshade: Washi Japanese paper
Dimming: 1-10 V
Dimming: DALI
Canopy: Rectangular. Dimming: 1-10 V
Canopy: Rectangular. Dimming: DALI
P3 lampshade: Washi Japanese paper
Dimming: 1-10 V
Dimming: DALI
Canopy: Rectangular. Dimming: 1-10 V
Canopy: Rectangular. Dimming: DALI
P3 lampshade: Washi Japanese paper
Dimming: 1-10 V
Dimming: DALI
Canopy: Rectangular. Dimming: 1-10 V
Canopy: Rectangular. Dimming: DALI
P4 lampshade: Washi Japanese paper
Dimming: 1-10 V
Dimming: DALI
Canopy: Rectangular. Dimming: 1-10 V
Canopy: Rectangular. Dimming: DALI
P4 lampshade: Washi Japanese paper
Dimming: 1-10 V
Dimming: DALI
Canopy: Rectangular. Dimming: 1-10 V
Canopy: Rectangular. Dimming: DALI
